The PV breaker at current continuous.
Max voltage up to 600 AC/DC, 10A, 2 poles
The series, BB1 mini PV breakers are mainly used on solar cabinets DC, controllers, etc. The main functions are protection against overloads, anti-reflux protection and protection against short circuits. The scientific design of an arc extinguishing system to maintain a more secure solar system.
Electric characteristics |
|
| Type | BB1-63 |
| In line with | IEC60947-2/GB14048.2 |
| Pole | 2 P |
| Nominal operating voltage | 600V Dc |
| Nominal max current. | 63A |
| Rated current | 10A |
| Rated insulated voltage | 600V DC |
| Nominal voltage of impulse | 4 KV |
| Ultimate breaking capacity | 6 KA |
| Breacking capacity | 100.00% |
| Type of curve | B |
| Trigger type | Thermal type |
| Life/cycle time of operation | |
| Current value | 20000 |
| Standard value | 8500 |
| Current value | 4000 |
| Standard value | 1500 |
| Installation environment | |
| Protection against the instrusion | All sides IP40, connection terminal Ip 20 |
| Cross-section of the terminals | 2.5 - 25 mm³ |
| Operating temperature | -25 ° C / 70 ° C. |
| Storage temperature | -40 ° C / + 85 ° C |
| Moisture and heat resistance | II (when the humidity reaches 55 ° C, relative humidity 95%) |
| Shock resistance | 2.6 IEC 60068 + |
| Resistance to impact |
2.27 IEC60068 |
