• Three-phase hybrid inverter SolaX X3-HYBRID-5.0-D G4.2

SolaX X3 Tri 10 kW Hybrid Inverter – X3-Hybrid-10.0-D G4.2

€3,698.32
Tax included
X3-HYBRID-10.0-D-G4.2
0768563820090

SolaX X3-Hybrid 10 kVA: Your Smart Power Station

Discover the SolaX X3 10 kVA three-phase hybrid inverter, the ideal solution for optimizing your solar energy production and reducing your electricity bill. Thanks to its exceptional performance and flexibility, it offers you a degree of energy autonomy and significant savings.

Why choose SolaX X3-Hybrid 10 kVA?

  • High performance: Maximizes solar energy production and offers high efficiency.
  • Maximum flexibility: Adapts to all solar and battery system configurations.
  • Reliability: Ensures continuous power supply in case of grid outage.
  • Simplified installation: Quick and intuitive commissioning.

Key benefits:

  • Smart hybrid mode: Combines solar energy, grid power, and storage for optimized management.
  • Remote monitoring: Control your installation in real-time through a dedicated app.
  • UPS function: Ensures continuous power to essential devices during power outages.
  • Expandability: Ability to connect multiple inverters in parallel to increase power.

Ideal for:

  • Residential and commercial buildings
  • Industrial installations
  • Large-scale self-consumption projects

Ready to achieve energy independence?
Contact us to discuss your project and receive personalized advice.

Comments (0)

No customer reviews for the moment.

SolaX 10kVA hybrid solar inverter: Optimised power and efficiency

SolaX Power is pleased to announce the launch of the X-Hybrid commercial three-phase inverter for battery storage. The three-phase range includes inverters from 5 to 10 kW and, thanks to the possibility of installing several inverters in parallel, scalable battery storage for commercial applications is now a reality. The inverter is equipped with EPS (Emergency Power Supply) function only when supported by additional inverters, has several communication options and can be remotely controlled.

High efficiency

  • 150% oversized PV and 110% overload output
  • Maximum 150% overload output
  • Superior load and discharge efficiency, up to 97.5%.
  • Integrated shadow tracking function

Economical

  • DC input current of up to 16A, compatible with high-power solar panels.
  • Stores excess energy from PV to battery
  • Low start-up output voltage enables inverter to work longer.
  • Less energy loss from battery to inverter

Intelligent

  • Switchover time <10ms
  • Fast configuration with U-disk
  • Compatible with lithium and lead-acid batteries
  • Compatible with CTs, loads respond in 0.3s
  • Intelligent load management (e.g.: heat pump). (e.g.
  • heat pump)
  • Parallel function on and off-grid, up to 150kW 5
  • working modes, 2 charging periods available
  • Ready for VPP, auxiliary service on the electricity market.
  • Unbalanced three-phase output 50% of rated output power on a single phase maximum

Safety

  • IP65 protection level
  • SPD integrated

Features

Password for parameter entry: 2014

INPUT
Max. power of photovoltaic panels (Wp) 15000
Max. DC voltage.
(V) 1000
Start-up voltage (V) 200
Nominal DC operating voltage (V) 640
MPPT voltage range (V) 180 -
950
Number of MPP trackers/strings per MPP tracker
(2/1)
Maximum input current per MPPT (A) 26/16
short-circuit current
circuit per MPPT (A) 30/20
AC
AND INPUT
Nominal AC power (VA) 10000
Max. AC power
(VA) 11000
Max. AC current (A) 16,1
Max.
AC input apparent power (VA)

20000
AC current max.
(A) 32,0
Rated mains voltage (AC voltage range) (V) 415/240; 400/230;
380/220
Nominal mains frequency/range (Hz) 50/60
Displacement power factor
.8 capacitive - 0.8 inductive
THDi, nominal power (%) <3
BATTERY
Battery type Li-ion battery/Lead-acid battery (under development)
Battery voltage range (V) 180 -
650
Maximum continuous charge/discharge current (A) 30
(OFF-GRADE OR EMERGENCY) (WITH BATTERY)
Nominal output power (W) 10000
Peak apparent power (VA) 15000,60s
Maximum continuous current (A) 14.5
Rated voltage (V) ;
Frequency (Hz) 400/230; 50/60
Switching time (ms) <10
Parallel operation

Yes
SYSTEM
MPPT efficiency (%) 98.0
European efficiency (%) 97,7
Battery charge/discharge efficiency (%)*1 98.5 / 97.5
Standby power consumption (night) (W) <5
Degree of protection (to IEC 60529) IP65
Operating temperature range (°C)
to + 60 (derating to 45)
Max. operating altitude.
(m
< 3000
Humidity(%)
to 100
Typical noise level (dB) <
35
Storage temperature (°C)
-+ 70
Dimensions (L x W x D) (mm) 503 x 503 x 199
Weight (kg) 30
Cooling type Natural
Communication interfaces CT/ Counter (optional) / RS485/ External control (optional :
Pocket WiFi/Lan/4G)/ DRM/ USB Upgrade/NTC (optional)
STANDARD
Safety EN/IEC62109-1/-2
IEC/EN 61000,
NB/T 32004
Certification
/ G99 / G98 / AS4777 / EN50549 / CEI 0-21 / IEC61727 / PEA / MEA / NRS-097-2-1/ RD1699 / TOR
X3-HYBRID-10.0-D-G4.2

Data sheet

Inverter power in VA
10000 VA
Phase
Triphasé
Number of MPPT
2 MPPT
Inverter type
Hybrid

Specific References

UPC
768563820090
EAN13
0768563820090
